300W Portable Laser Cleaning Machine For Foaming Mould

    Buy cheap 300W Portable Laser Cleaning Machine For Foaming Mould from wholesalers

    Buy cheap 300W Portable Laser Cleaning Machine For Foaming Mould from wholesalers
    • Buy cheap 300W Portable Laser Cleaning Machine For Foaming Mould from wholesalers
    • Buy cheap 300W Portable Laser Cleaning Machine For Foaming Mould from wholesalers

    300W Portable Laser Cleaning Machine For Foaming Mould

    Ask Lasest Price
    Brand Name : Super Fast - CK
    Model Number : CK-FC-300W
    Certification : CE, ISO
    Price : 40000USD-60000USD
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 200sets/month
    Delivery Time : 5-7 days
    • Product Details
    • Company Profile

    300W Portable Laser Cleaning Machine For Foaming Mould

    Foaming Mould Laser Cleaning System Portable 300W Laser Cleaning Machine For Die Molds


    Technical parameters


    Electrical characteristics
    No.CharacteristicTest ConditionsMinTypical valueMaxUnit
    1Supply voltage220210220230AC
    2Maximum current lossPout=Pnom456A
    3Total power consumption1440143014401450W
    4Fiber optic cable5558M
    General characteristics
    L/NCharacteristicsParametersUnit
    1Output Fiber cable5M
    2Average power output350±5W
    3Power adjust range1-100%
    4Max. Pulse energy15MJ
    5Pulse width80-500NS
    6Cooling methodAir-cooling
    7Laser levelLevel 4
    8Max. power consumption1440W
    9Center wavelength1064NM
    10Voltage220AC
    11Work temperature0-60
    12Lasser source dimension558*378.5*425MM
    13Machine dimension850*500*950MM
    14Machine weight133KG

    Advantages of laser cleaning the moldings


    Compared with traditional cleaning methods such as Chemical mold cleaning liquid or sandblasting, laser cleaning has huge advantages:

    1) Only use electricity, without any other consumables, energy-saving, and cost-saving.

    2) Low noise, no chemical pollution, environmental protection, avoid environmental troubles;

    3) Laser non-contact cleaning, no damage to the mold base material, knife edges, ridges, and prolongs the life of the molds;

    4) Retain the electroplated layer, no damage to the product finish;

    5) Efficient and thorough cleaning to improve productivity and product quality;

    6) Automatic cleaning, labor cost saving;

    7) No temperature effects, both cold and hot molds can be cleaned;

    8) Flexible cleaning methods, hand-held cleaning, automatic cleaning optional;

    9) No cleaning dead end, no shape limitation, where the laser can reach can be cleaned


    Technical Advantages:
    Clean or remove the surface paint layer with high efficiency.
    Accurate cleaning and rust removal effects;
    No damage to the substrate;
    Low cost, low consumption;
    Fast investment recovery;
    No need to sand grit or chemical;
    Easy operation


    Product Application:


    Applications of laser cleaning machine
    Laser cleaning machine is widely used for the surface laser degreasing, laser paint removal, laser removal of zinc, laser film removal, laser cleaning, welding bead cleaning, coating cleaning and etc.

    Machine brief introduction
    The laser cleaning Machine is a new generation of industrial surface cleaning laser system. It adopts the advanced laser source, laser optical scanners and control system to meet the requirements of metal surface cleaning process.

    Laser dry cleaning method of laser cleaning machine
    Use pulses laser to clean rust directly, it will generate vibration after the laser energy is absorbed by the base or particles, then seperate the base and comtaminant.


    Machine Features


    1. Clean or remove the surface paint layer quickly and cleanly;
    2. Accurate cleaning and paint removal effects;
    3. no damage to the substrate;
    4. low cost;
    5. Fast investment recovery;
    6. No need to sand grit or chemical;
    7. The equipment does not need to be set up;
    8. Low noise;
    9. There are no maintenance requirements.
