300W High Power Tire Mold Laser Cleaning Machine Portable Laser
Rubber Stains Cleaning System
Advantages of laser cleaning the moldings
Compared with traditional cleaning methods such as Chemical mold
cleaning liquid or sandblasting, laser cleaning has huge
advantages:
1) Only use electricity, without any other consumables,
energy-saving, and cost-saving.
2) Low noise, no chemical pollution, environmental protection,
avoid environmental troubles;
3) Laser non-contact cleaning, no damage to the mold base material,
knife edges, ridges, and prolongs the life of the molds;
4) Retain the electroplated layer, no damage to the product finish;
5) Efficient and thorough cleaning to improve productivity and
product quality;
6) Automatic cleaning, labor cost saving;
7) No temperature effects, both cold and hot molds can be cleaned;
8) Flexible cleaning methods, hand-held cleaning, automatic
cleaning optional;
9) No cleaning dead end, no shape limitation, where the laser can
reach can be cleaned
Technical parameters
| Electrical characteristics |
| No. | Characteristic | Test Conditions | Min | Typical value | Max | Unit |
| 1 | Supply voltage | 220 | 210 | 220 | 230 | AC |
| 2 | Maximum current loss | Pout=Pnom | 4 | 5 | 6 | A |
| 3 | Total power consumption | 1440 | 1430 | 1440 | 1450 | W |
| 4 | Fiber optic cable | 5 | 5 | 5 | 8 | M |
| General characteristics |
| L/N | Characteristics | Parameters | Unit |
| 1 | Output Fiber cable | 5 | M |
| 2 | Average power output | 350±5 | W |
| 3 | Power adjust range | 1-100 | % |
| 4 | Max. Pulse energy | 15 | MJ |
| 5 | Pulse width | 80-500 | NS |
| 6 | Cooling method | Air-cooling | |
| 7 | Laser level | Level 4 | |
| 8 | Max. power consumption | 1440 | W |
| 9 | Center wavelength | 1064 | NM |
| 10 | Voltage | 220 | AC |
| 11 | Work temperature | 0-60 | ℃ |
| 12 | Lasser source dimension | 558*378.5*425 | MM |
| 13 | Machine dimension | 850*500*950 | MM |
| 14 | Machine weight | 133 | KG |
Will laser cleaning damage my material?
The laser beam will leave no chemical, mechanical or thermal strain
on the substrate itself. This means you can safely pulse the
surface layer of your material.
Furthermore, as laser systems, particularly fiber lasers, offer the
user a great deal of control, the depth at which you want to work
at can be highly accurate. This is useful for applications where
you may only want to remove a very thin layer, such as a topcoat of
paint and not the primer below.
Product Application:
| Metal or glass surface coating removal, rapid paint removal; |
| Grease, resin, gum, dust, stains, and produce residue removal; |
| Cultural relics cleaning, rock cleaning, exterior cleaning of
buildings. |
| Treatment before welding, bonding, remove paint, rust, grease, weld
oxide or residue; |
| Roughening of metal surface; |
| Mold cleaning, such as tire mold, electronic mold, food mold and
etc.; |
| Aerospace weapons, ship manufacture or maintenance, paint and rust
removal; |
| Quick rust and various oxides removal; |
| Treatment for precision parts, oil removal; |
| Metal surface cleaning in narrow space; |
| Quick cleaning of nuclear power unit maintenance; |
After-sale service
| 1. 3-year guarantee for laser source. |
| 2. Full technical support by e-mail, call, and video |
| 3. Lifelong maintenance and spare parts supply. |
| 4. Free design of fixtures as customers required. |
| 5. Free training installation and operation for the staff. |
