Brand Name : | CK |
Model Number : | CK-FC-100W |
Certification : | CE, ISO |
Price : | 20000USD-26000USD |
Payment Terms : | L/C, T/T, Western Union |
Supply Ability : | 200 sets/month |
Delivery Time : | 5-7 days |
CE Certificated Laser Derusting Tool 100W Portable Laser Rust Remover Machine 220V
Product parameters
Item | L/N | Characteristics | Test Conditions | Min. | Typical | Max. | Unit |
Electrical Characteristics | 1 | Power Voltage | 220 | 210 | 220 | 230 | AC |
2 | Maximum current loss | Pout=Pnom | 4 | 5 | 6 | A | |
3 | Total Power | 600 | 590 | 600 | 610 | W | |
4 | Fiber Cable | 5 | 5 | 5 | 10 | M | |
General Characteristics | 1 | Working temperature range | 0 | / | 60 | ℃ | |
2 | Storage temperature | -10 | / | 60 | ℃ | ||
3 | Laser power | 100 | W | ||||
4 | Peak power | >10KW | KW | ||||
5 | Cooling method | Air Cooling | |||||
6 | Laser level | 4 Class | |||||
7 | Pulse energy | 1.5mJ | mJ | ||||
8 | Laser wavelength | 1064 | nm | ||||
9 | Preheat time | Reach to start operation | 0 | s | |||
Achieve complete stability | 10 | ||||||
10 | Humidity | 10 | / | 95 | % | ||
11 | Laser machine size | L647*W440*H859 | mm | ||||
12 | Weight | 70 | kg |
Product Description
The laser cleaning system is a high-tech product of the new generation of surface cleaning. It can be used for a
wide range of traditional cleaning processes such as chemistry and grinding. It has the characteristics of no grinding,
non-contact, low thermal efficiency and suitable for various materials. It is considered to be the most reliable.
The most effective new generation cleaning solution.
Application Scope
Metal surface de-rusting, Surface painting removal or pre-treatment before painting, Surface oil, stains, dirt cleaning, Surface coating removal, Welding surface/spray surface pretreatment, Stone surface dust and attachment removal, Rubber mold residue cleaning and so on.
Application Field:
The marine industry, auto parts, rubber molds, high-end machine
tools, tire molds, rails, environmental protection industry and
other industries.
FAQ
Will laser cleaning damage my material?
The laser beam will leave no chemical, mechanical or thermal strain
on the substrate itself. This means you can safely pulse the
surface layer of your material. Furthermore, as laser systems,
particularly fiber lasers, offer the user a great deal of control,
the depth at which you want to work at can be highly accurate. This
is useful for applications where you may only want to remove a very
thin layer, such as a topcoat of paint and not the primer below.
Q1: How can I get the best machine for me?
Contact me,we will suggest you the best machine for your
application.
Q2: I never use this kind of machine before, is it easy to operate?
Yes, it's extremely easy! Inno will send you manual and guide video
in English, it can teach you how to operate the machine. If you
still can not learn how to use it, we can help you by remote
service. Or we can talk by phone, email or other contact ways.
Q3: If the machine has problem in my place, how could I do?
Call me, we will handle your problems and transfer to related
person. We could send free parts to you in warranty period if
machines have any problem under "normal use".
Q4: This model is not suitable for me, do you have more models
available?
Yes, just contact me, he will show you the suitable machine
according to your information.
Q5: What's the guarantee, in case the machine breaks down?
The machine has two years guarantee.
Q6: How about the documents after shipment?
After shipment,i will send all original documents to you, including
Packing List, Commercial Invoice, B/L, and other certificates as
required by clients.
Q7: How long is the delivery time?
For standard machines, it would be 5-7 days; For customized
machines, negotiable.
Q8: How's the payment?
Telegraphic Transfer (T/T). Special payment term according to your
country policy is accepted.
![]() |
