500W Strong Power Car Paint Remover Machine Q-switch Fiber Laser
Source Rust Removal System
Advantages of SUPER FAST LASER?
1, Factory with advanced management and production facilities.
2, Own R&D team, the technology always in the leading position,
3, Mass production, prompt delivery, LOWEST PRICE.
4, Stable quality with series hardware & software patents and
certificates,
5, 3-YEAR WARRANTY. Machine with quality problem can be changed by
a new machine,
6, 24 hours responsible, 5-star service,
7, A great variety of goods, we can provide all series of
intelligent laser equipment,
8, Any type of customized products available.
Tecnical parameters
| L/N | Characteristics | Test Condition | Min | Typical | Max | Unit |
| 1 | Power Voltage | 220 | 210 | 220 | 230 | V/AC |
| 2 | Maximum current | Pout = Ponm | | | ≈25 | A |
| 3 | Maximum Power | Pout = Ponm, T=20℃ | | | ≈6.5 | Kw |
| 4 | Working temperature | | 0 | | +40 | ℃ |
| 5 | Storage temperature | | -10 | | +60 | ℃ |
| 6 | Cooling method | Water cooling |
| 7 | Scan Width | 1-160 | mm |
| 8 | Peak power | 200Kw |
| 9 | Humidity | | 10 | | 95 | % |
| 10 | Laser machine size | L1100 x W 840 x H1150mm | mm |
| 11 | Weight | 250 | Kg |
| 1 | Working Mode | Pulse |
| 2 | Polarization states | Random |
| 3 | Beam parameter product | Pout = Ponm | | 7.7 | | mm*mrad |
| 4 | Central wavelength | Pout = Ponm | 1060 | 1064 | 1070 | nm |
| 5 | Spectral width (3dB) | Pout = Ponm | | 8 | 15 | nm |
| 6 | Average power (Pnom) | | 500 | | | W |
| 7 | Power adjust range | | 10 | | 100 | % |
| 8 | Maximum monopulse energy | 350ns/16KHz | | | 30 | mJ |
| 9 | Pulse duration adjust range | | 200 | | 350 | ns |
| 10 | Laser beam pulse width (FWHM) | 350ns/16KHz | | | 95 | ns |
| 11 | Pulse repetition frequency | 250-350ns | 1 | | 200 | KHz |
| 200-220ns | 1 | | 400 |
| 12 | Output power instability | Pout = Ponm | | | 5 | % |
| 13 | Output beam divergence angle | | | | 70 | mrad |
| 14 | Output beam ellipticity | | 90 | | | % |
| 15 | Fiber cable length | | | 7 | | m |
| 16 | Output fiber type | 220/600 QBH | |
| 17 | Output fiber core diameter | 220 | um |
Product Applications and field
| Applications | 1. Metal surface rust removal |
| 2. Paint cleaning |
| 3. Oil-stain, contaminant cleaning |
| 4. Coating surface cleaning |
| 5. Welding/Coating surface pre-treatment |
| 6. Stone figure surface dust & attachment cleaning |
| 7. Plastic mold residues cleaning |
| Industries | 1. Molding |
| 2. High-end machine tools |
| 3. Ship |
| 4. Vehicle parts |
| 5. Rubber tire |
| 6. Environmental protection industry |
| 7. Printing Industry |
| 8. Road track |
| 9. Microelectronics |
After-sale service
| 1). 2 years quality guaranty, the fiber laser cleaning machine with
main parts(excluding the consumables) shall be changed free of
charge(some parts will be maintained) in case of any problem during
the warranty period. |
| 2). Lifetime maintenance free of charge. |
| 3). Free training course at our plant. |
| 4). 24 hours of online service and email each day, free technical
support. |
| 5). The machine has been tested and inspected strictly before
delivery. |
| 6). Provide technical services to the door(We have professional
engineers to offer machine installation commissioning and
maintenance) if customers pay the charges of the ticket |
| 7). if you have any problem during your use. you need our
technician to judge |
Machine Features
(1). The specialized factory only focuses on laser cleaning machine
mass production, reliability.
(2). Non-contact cleaning, no damage to the workpiece
(3). Precision focusing, selective cleaning, desired cleaning area
can be applied to the workpiece
(4). No need chemical detergent, no consumable. Safe &
environment-friendly.
(5). Easy to operate, Either portable or equipped with a robot for
automatic cleaning.
(6). Any types of automatic cleaning equipment can be customized
according to the users' requirements.
(7). High cleaning efficiency, time-saving.
(8). Stable laser cleaning system, free maintenance.
