High Stable Industrial Laser Cleaning Machine Non Contact 50W 100W
200WSpecification
| Items | Parameters |
| Cleaning Power | 50W | 100W | 200W | 500W |
| Current Consumption | Pout = Ponm / 5A | Pout = Ponm / 5A | Pout = Ponm / 5A | Pout = Ponm / 25A |
| Max. Power | 400W | 600W | 900W | 6.5KW |
| Power Voltage | AC 110/220V | AC 110/220V | AC 110/220V | AC 110/220V |
| Cooling Method | Air Cooling | Air Cooling | Air Cooling | Water Cooling |
| Laser Class | Level 4 | Level 4 | Level 4 | Level 4 |
| Pulse Energy | 1.5mJ | 1.5mJ | 8mJ | 30mJ |
| Fiber Optical Cable | 5m(Customizable) | 5m(Customizable) | 5m(Customizable) | 7m(Customizable) |
| Laser Wavelength | 1064nm | 1064nm | 1064nm | 1064nm |
| Scan Width | 1-120mm | 1-120mm | 1-120mm | 1-160mm |
| Preheat Time | 10-30s | 10-30s | 10-30s | 10-30s |
| Working Condition | A flat place without vibration and impact | A flat place without vibration and impact | A flat place without vibration and impact | A flat place without vibration and impact |
| Working Temperature | 0-60 ℃ | 0-60 ℃ | 0-60 ℃ | 0-60 ℃ |
| Storage Temperature | -10~+60℃ | -10~+60℃ | -10~+60℃ | -10~+60℃ |
| Machine size | L462 x W 260 x H562 (855mm with pull rod) | L647 x W 440 x H859mm | L647 x W 440 x H859mm | L1100 x W 840 x H1150mm |
| Net Weight | 32Kgs | 70Kgs | 70Kgs | 250Kgs |
Application
a, Metal surface rust removal
b, Paint cleaning
c, Oil stain, contaminant cleaning
d, Coating surface cleaning
e, Welding/Coating surface pre-treatment.
F, Stone figure surface dust & attachment cleaning.
G, Plastic mold residues cleaning
Features
a, First high power fiber laser cleaning machine in China.
b, Non-contact cleaning, no damage to the workpiece
c, Precision positioning, selective cleaning, desired cleaning area
can be applied to the workpiece
d, No need chemical detergent, no consumable. Safe &
environment-friendly.
e, Easy to operate, Either portable or equipped with a robot for
automatic cleaning.
f, High cleaning efficiency, time-saving.
g, Stable laser cleaning system, free maintenance.
FAQ
1) 2 years quality warranty.
2) Lifetime maintenance free of charge.
3) Free training course for any application.
4) 24 hours of online service, free technical support.
5) The machine has been strictly tested and inspected before
delivery.
6) Door to door technical services(We have professional engineers
to offer machine installation
7)We can change a new machine if there is quality problem that is
not easy to be solved.
