100w Laser Cleaning System Laser Descaling Tool For Molding
IndustrialTechnical parameters
| Item | L/N | Characteristics | Test Conditions | Min. | Typical | Max. | Unit |
| Electrical Characteristics | 1 | Power Voltage | 220 | 210 | 220 | 230 | AC |
| 2 | Maximum current loss | Pout=Pnom | 4 | 5 | 6 | A |
| 3 | Total Power | 600 | 590 | 600 | 610 | W |
| 4 | Fiber Cable | 5 | 5 | 5 | 10 | M |
| General Characteristics | 1 | Working temperature range | 0 | / | 60 | ℃ |
| 2 | Storage temperature | -10 | / | 60 | ℃ |
| 3 | Laser power | 100 | W |
| 4 | Peak power | >10KW | KW |
| 5 | Cooling method | Air Cooling | |
| 6 | Laser level | 4 Class | |
| 7 | Pulse energy | 1.5mJ | mJ |
| 8 | Laser wavelength | 1064 | nm |
| 9 | Preheat time | Reach to start operation | 0 | s |
| Achieve complete stability | 10 |
| 10 | Humidity | 10 | / | 95 | % |
| 11 | Laser machine size | L647*W440*H859 | mm |
| 12 | Weight | 70 | kg |
Product Description
The laser cleaning system is the high-tech product of the new
generation of metal surface cleaning. It can be widely used for a
range of traditional or industrial cleaning processes such as
chemistry, ship industry, Aviation industry, Automotive industry,
Cultural relics restoration, Molding industry, Railway industry,
Construction industry, Oil pipeline, and grinding cleaning. It has
the characteristics of no grinding, non-contact, low thermal
efficiency, environmental friendly and suitable for various
materials. It is considered to be the most reliable. So the laser
cleaning machine is defined as the most effective new generation
cleaning solution.
Machine applications
1. Metal surface cleaning in narrow space, no died-end;
2. Mold cleaning, such as tire mold, electronic mold, food mold,
injection mode and etc.;
3. Grease, resin, gum, dust, stains, and produce residue removal;
4. Pre-treatment of welding, bonding, remove paint, rust, grease,
weld oxide or residue;
5. Quick rust and various oxides cleaning;
6. Metal surface coating removal, rapid painting removal;
7. Cultural relics cleaning, rock cleaning, exterior cleaning of
buildings.
8. Roughening of metal surface;
9. Treatment for precision parts;
10. Aerospace weapons, ship manufacture or maintenance and etc;
11. Nuclear power unit maintenance;
Main features
| 1. It can protect the surface of the cleaning object. Make sure
that it is intact. For different dirt on different substrate
surfaces, the fiber laser cleaning machine can selectively clean
the dirt without damaging the substrate by setting laser parameters
such as spot size, single pulse energy, pulse width, repetition
rate, etc. |
| 2. It’s environmentally friendly and green cleaning. |
| 3. It can clean the surface of the fragile material. Since laser
cleaning is non-contact between the machine and the object, it is
convenient to carry out the cleaning operation. And very easy to
clean up the area in which another conventional cleaning method
cannot be reached. |
| 4. Fast speed at low cost. |
